#pragma once
#include <iostream>
#include <string>
#include <thread>
#include <mutex>
#include <vector>
#include <winsock2.h>
#include <ws2tcpip.h>
#include <opencv2/opencv.hpp>
// Ensure Windows socket libraries are linked
#pragma comment(lib, "Ws2_32.lib")
class NetworkCamera {
public:
NetworkCamera();
~NetworkCamera();
// Establishes connection to the Raspberry Pi
bool connectToDevice(const std::string& ipAddress, int port);
// Disconnects and shuts down background threads cleanly
void disconnect();
// Call this after your settle delay to get the absolute freshest frame
cv::Mat getLatestFrame();
bool isConnected() const { return m_connected; }
private:
// Background thread function that continuously drains the socket network buffer
void captureLoop();
// Network handles
SOCKET m_connectSocket;
bool m_connected;
bool m_running;
// Background streaming thread
std::thread m_captureThread;
// Double-buffering architecture
cv::Mat m_bufferA;
cv::Mat m_bufferB;
cv::Mat* m_writePtr; // Where the network thread decodes the incoming image
cv::Mat* m_readPtr; // Where the main loop safely reads from
std::mutex m_bufferMutex;
};
#include "NetworkCamera.h"
NetworkCamera::NetworkCamera()
: m_connectSocket(INVALID_SOCKET), m_connected(false), m_running(false) {
// Point our buffers to our local matrices
m_writePtr = &m_bufferA;
m_readPtr = &m_bufferB;
}
NetworkCamera::~NetworkCamera() {
disconnect();
}
bool NetworkCamera::connectToDevice(const std::string& ipAddress, int port) {
// Initialize Winsock
WSADATA wsaData;
if (WSAStartup(MAKEWORD(2, 2), &wsaData) != 0) {
std::cerr << "Winsock initialization failed.\n";
return false;
}
// Create Socket
m_connectSocket = socket(AF_INET, SOCK_STREAM, IPPROTO_TCP);
if (m_connectSocket == INVALID_SOCKET) {
std::cerr << "Socket creation failed.\n";
WSACleanup();
return false;
}
// Setup hint structure
sockaddr_in clientService;
clientService.sin_family = AF_INET;
clientService.sin_port = htons(port);
inet_pton(AF_INET, ipAddress.c_str(), &clientService.sin_addr);
// Connect to Raspberry Pi
if (connect(m_connectSocket, (SOCKADDR*)&clientService, sizeof(clientService)) == SOCKET_ERROR) {
std::cerr << "Failed to connect to Pi camera server.\n";
closesocket(m_connectSocket);
WSACleanup();
return false;
}
m_connected = true;
m_running = true;
// Spin up the background network thread
m_captureThread = std::thread(&NetworkCamera::captureLoop, this);
return true;
}
void NetworkCamera::disconnect() {
if (m_running) {
m_running = false;
// Close socket to unblock any pending recv() calls in the thread
if (m_connectSocket != INVALID_SOCKET) {
closesocket(m_connectSocket);
m_connectSocket = INVALID_SOCKET;
}
if (m_captureThread.joinable()) {
m_captureThread.join();
}
WSACleanup();
m_connected = false;
}
}
void NetworkCamera::captureLoop() {
while (m_running) {
uint32_t imageSize = 0;
// 1. Read the 4-byte header telling us how big the upcoming image is
int result = recv(m_connectSocket, reinterpret_cast<char*>(&imageSize), sizeof(imageSize), 0);
if (result <= 0 || !m_running) break;
// Convert from network byte order to host byte order (just in case)
imageSize = ntohl(imageSize);
// 2. Read the actual image payload bytes (looping until full size reached)
std::vector<uchar> byteBuffer(imageSize);
int totalBytesRead = 0;
while (totalBytesRead < static_cast<int>(imageSize) && m_running) {
int bytesLeft = imageSize - totalBytesRead;
int received = recv(m_connectSocket, reinterpret_cast<char*>(byteBuffer.data() + totalBytesRead), bytesLeft, 0);
if (received <= 0) break;
totalBytesRead += received;
}
if (totalBytesRead < static_cast<int>(imageSize)) continue; // Fragmented or broken frame
// 3. Decode the compressed JPEG bytes straight into our current "Write" buffer
// This takes the heavy CPU compression-lifting out of your main logic thread.
cv::imdecode(byteBuffer, cv::IMREAD_UNCHANGED, m_writePtr);
if (!m_writePtr->empty()) {
// 4. Instantly swap pointers. The new image becomes readable,
// and the old image memory space is recycled for the next incoming data.
std::lock_guard<std::mutex> lock(m_bufferMutex);
std::swap(m_writePtr, m_readPtr);
}
}
}
cv::Mat NetworkCamera::getLatestFrame() {
std::lock_guard<std::mutex> lock(m_bufferMutex);
// Returns a fast, shallow-copy header of the matrix.
// It is fully isolated and thread-safe because the capture loop will
// write to the *other* buffer pointer on its next iteration.
return *m_readPtr;
}
